the tangent vertical The tangent vertical alignment of a sec

The tangent vertical alignment of a section of proposed highway is shown in the figure below. The horizontal distance (feet) between P.V.I. and P.V.I.2 is most nearly: (A) 3395 (B) 3400 (C) 3410 (D) 3425 P.VJ., STATION 42+00.00 P.v.i., ELEVATION 436.55 BRIDGE STRUCTURE STATION 73+00.00 ELEVATION 365.94 P.V.T 1 = 1400 FT CURVE 1 P.V.T.2 CURVE 2 1500 FT T P.V.C.1 93 = +2.0% P.V.2 STATION 76+00.00 .P.V.1.2 ELEVATION 334.56 PROPOSED HIGHWAY VERTICAL ALIGNMENT NOT TO SCALE

Solution

As per the given figure it is observed that the horizontal distance between the two point is 3410.
