If given a Thevenin\'s Equivalent circuit has Vth=16.5V and Rth=43.17kohms determine and draw the Norton Equivalent circuit

thevinins resistance=norton resistance=43.17 kohms

thevinis equivalent circuit is the series connection of thevinins voltage, thevinins resistance and load resistance.

nortons equivalent circuit is the parallel connection of norton current, norton resistance and load resistance.
