By looking at this problem how can one tell that Fb is to the right (+)?

Question: 91:Compute the horizontal and vertical components 01 Compute the horizontal and vertical components of force at pin B. The T=100 N and passes over each of the three pulleys. mpute the horizontal and vertical components of force at pin B. The belt is subjected to a tension of 30° 45° View comments (2) > Best Answer

Belt is a tension force member. thus only tensile forces exists in that. And tensile forces acts away from the point of application of load.

It can also be said based on the free body diagrams of the individual pulleys.

since pulley at A has a tensile force of T downwards, same tensile force acts in the belt towards pulley B.

considering the free body diagram of pulley B, if the tensile force T (left side ) acts towards pulley A, the counter force T (right side) must act away from B.
