Consider the circuit in Figure 1. It is a 4-bit synchronous counter which uses four Toggle flip-flops. The counter increments its count on each positive edge of the clock if the Enable signal is asserted. The counter is reset to 0 by using the (asynchronous) Reset signal. You are to implement a 16-bit counter of this type. Figure 1. A 4-bit counter. Write a VHDL file that defines a 16-bit counter by using the structure depicted in Figure 1, and compile the circuit. Look at your Compilation Report, under Timing Analyzer. What is the maximum frequency, F_max, at which your circuit can be operated?

Solution

First define the T flip-flop entity and use it as component in the structural design.

entity T_ff is,

port(T,Clock,Clear: in std_logic;

     Q:out std_logic);

end T_ff;

architecture arc_T_ff of T_ff is,

signal Q_temp: std_logic;

begin

process(Clock)

begin

if Clear ==’1’ then Q_temp<=0;

elsif clk’event and clk=’1’ then

if T=1 then Q_temp<=not Q_temp;

else

Q_temp<=Q_temp;

end

end

end

end arc_T_ff;

Use T_ff component and write the structural code for the 4-bit synchronous counter.

entity syn_counter is,

port(T,Clock,Enable,Clear: in std_logic;

     Q:out std_logic_vector (3 downto 0);

end syn_counter;

architecture arc_ syn_counter of syn_counter is,

signal temp1,temp2,temp3, E1,E2,E3: std_logic;

component T_ff

port(T,Clock,Clear: in std_logic;

     Q:out std_logic);

end component;

T1: T_ff port map(Enable,Clock,Clear,temp1);

E1<=temp1 and Enable;

T2: T_ff port map(E1,Clock,clear,temp2);

E2<=temp2 and E1;

T3: T_ff port map(E2,Clock,clear,temp3);

E3<=temp3 and E2;

T4: T_ff port map(E3,Clock,clear,temp4);

Q<=temp1& temp2& temp3& temp4;

end arc_ syn_counter;
