Implementing a basic directorytree structure that is derived

Implementing a basic directory-tree structure that is derived from a base tree structure.

#ifndef SRC_TREENODE_HPP_
#define SRC_TREENODE_HPP_

#include <iostream>
#include <vector>

//#define USE_OSS

#ifndef USE_OSS
#define OUT std::cout
#else
#include <sstream>
extern std::ostringstream oss;
#define OUT oss
#endif

namespace ensc251 {

static unsigned count = 0;

class TreeNode;

typedef TreeNode* (TreeNode::*action_func)(void);
typedef void (TreeNode::*traverse_func)(const TreeNode*);

class TreeNode
{
  typedef std::vector<TreeNode*> TreeNodePVect;

  protected:
   TreeNodePVect childPVector;

  public:
   TreeNode() {};
   TreeNode(const TreeNode& nodeToCopy) {
    // ***** this needs work *****
    if (nodeToCopy.childPVector.size())
     add_childP(nodeToCopy.childPVector[0]->clone());
   }

   virtual TreeNode* clone() const { return new TreeNode(*this); };

   virtual ~TreeNode() {
    // do not modify this insertion on OUT
    OUT << \"Destroying TreeNode with \" << childPVector.size() << \" children.\"<< std::endl;

    // ***** Complete this member function *****
   }

      void swap(TreeNode & other) // the swap member function (should never fail!)
      {
      // ***** fill this in if desired *****
      }

      TreeNode & operator = (TreeNode other) // note: argument passed by value, copy made!
      {
    // ***** Complete this code *****
          return *this; // by convention, always return *this
      }

   void add_childP(TreeNode* child) { /* ***** Complete this member function ***** */ }
   void add_children(const TreeNodePVect& childPV) { childPVector.insert(childPVector.end(), childPV.begin(), childPV.end()); }
   const TreeNodePVect& get_children() const { return childPVector; }

   TreeNode* traverse_children_post_order(traverse_func tf, action_func af)
   {
       for(auto childP : childPVector) {
           (childP->*tf)(this); // traverse child\'s children using tf
       }
       return (this->*af)();
   }

   TreeNode* traverse_children_pre_order(traverse_func tf, action_func af)
   {
    // ***** Complete this member function *****
   }

   TreeNode* traverse_children_in_order(traverse_func tf, action_func af)
   {
    // ***** Complete this member function *****
   }

   TreeNode* count_action()
   {
    count++;
    return nullptr;
   }

   void count_traverse(const TreeNode*)
   {
    traverse_children_post_order(count_traverse, count_action);
   }
   void reset_count() { count = 0; }
   unsigned get_count() const { return count; }

};
}

#endif /* SRC_TREENODE_HPP_ */

#include \"makeDirectoryTree.hpp\"

using namespace std;

int doStuff()
{
// call function to build directory tree in memory
auto root_dir1P = make_directory_tree(\".\", \"test_dir\");

if (root_dir1P) {
  root_dir1P->print_traverse(nullptr);
  OUT << endl;

  root_dir1P->reset_count();
  root_dir1P->count_traverse(nullptr);
  OUT << \"Count is \" << root_dir1P->get_count() << \"\ \" << endl;

  auto root_dir2 = Directory(*root_dir1P); // copy construction
  root_dir2.print_traverse(nullptr);
  OUT << endl;

  auto root_dir3P = make_directory_tree(\"test_dir\", \"Lectures\");
  if (root_dir3P) {
   root_dir2 = *root_dir3P; // overloaded copy assignment operation
   OUT << endl;

   delete root_dir3P;
   OUT << endl;
  }
  root_dir2.print_traverse(nullptr);
  OUT << endl;

  delete root_dir1P;
  OUT << endl;

} // destructor for root_dir2 called.
OUT << endl;

return 0;
}

// don\'t remove the below line.
#ifndef DONT_RUN_MAIN
int main()
{
int rv = doStuff();

#ifdef USE_OSS
std::string s = oss.str();
cout << s << endl;
#endif

return rv;
}
#endif

/* End of dirTree.cpp file */

* makeDirectoryTree.cpp

#include <dirent.h>
#include <sys/stat.h>
#include <algorithm> // for find

#include \"makeDirectoryTree.hpp\"

// The below function may be replaced. Don\'t worry about trying to understand
// this version.

// traverse directories on the filesystem starting at a certain point and build
// a directory tree in memory

Directory *make_directory_tree(const std::string& path, const std::string& dir_name)
{
using namespace std;

static vector<string> ignore_list = {\".\",\"..\"};

auto newPath = path + \"\\\\\" + dir_name;

DIR *dir;
if ((dir = opendir(newPath.c_str())) == nullptr)
{
     OUT << newPath.c_str() << \" Error while opening \" << newPath << endl;
     return nullptr;
}
auto new_entity = new Directory(dir_name);

struct dirent *dptr;
while ((dptr = readdir(dir)))
{
  if(find(ignore_list.begin(), ignore_list.end(), dptr->d_name) != ignore_list.end())
    continue;

  auto fullPath = newPath + \"\\\\\" + dptr->d_name;

  struct stat filestat;
  stat(fullPath.c_str(), &filestat);

  if(S_ISDIR(filestat.st_mode))
  {
   auto node = make_directory_tree(newPath, dptr->d_name);
   if (!node)
    // add directory with no files or subdirs in case of permission problem
    node = new Directory(dptr->d_name);
   new_entity->add_childP(node);
  }
  else {
   new_entity->add_file(dptr->d_name);
  }
}
return new_entity;
}

/*
* makeDirectoryTree.hpp

#ifndef SRC_MAKEDIRECTORYTREE_HPP_
#define SRC_MAKEDIRECTORYTREE_HPP_

#include \"Directory.hpp\"

Directory *make_directory_tree(const std::string& path, const std::string& dir_name)
;

#endif /* SRC_MAKEDIRECTORYTREE_HPP_ */

#include \"TreeNode.hpp\"

#ifdef USE_OSS
std::ostringstream oss;
#define OUT oss
#endif

#ifndef SRC_DIRECTORY_HPP_
#define SRC_DIRECTORY_HPP_

#include \"TreeNode.hpp\"
#include <iomanip>
#include <string>
#include <vector>

class Directory : public ensc251::TreeNode
{
typedef std::vector<std::string> stringVect;

private:
  std::string dir_name;
  stringVect file_names;

public:
  Directory(std::string m_dir_name): dir_name(m_dir_name) {}
  Directory(std::string m_dir_name, stringVect m_file_names): dir_name(m_dir_name), file_names(m_file_names) {}
  virtual Directory* clone() const { /* ***** Complete this member function ***** */ };
  void set_dir_name(const std::string& m_dir_name){ /* ***** Complete this member function ***** */ }
  const std::string & get_dir_name() { return dir_name; }
  void add_file(const std::string& m_fileName) { /* ***** Complete this member function ***** */ }
  void add_multiple_files(const stringVect& m_files) { file_names.insert(file_names.end(), m_files.begin(), m_files.end()); }
  const stringVect & get_files() const { return file_names; }

  TreeNode* print_action()
  {
   // Do not modify insertion on OUT in this member function!
   OUT << std::setw(20) << dir_name+\"\\t|\" << \" \";
   OUT << this->childPVector.size() << \" \";
   for (auto file : file_names)
   {
    OUT << \" -\" << file;
   }
   OUT << std::endl;
      return nullptr;
  }

  void print_traverse(const TreeNode*)
  {
   // ***** this needs work *****
   // ***** encode the rules in the instructions

   traverse_children_post_order(
     static_cast<ensc251::traverse_func>(print_traverse),
     static_cast<ensc251::action_func>(print_action));
  }
};

#endif /* SRC_DIRECTORY_HPP_ */

Solution
