Assembly manufacturing

2. Analyze the Staple Remover shown in Figure 2 using the Assembly Design Rules listed below Assembly Design Rules for Reducing Part Count i. Relative movement of Components i. Components MUST to be made of different materials for thermal, electrical or structural isolation iii. Allow access to other components for assembly & disassembly iv. Cost of assembly is less than Cost of Manufacturing as a Single unit v. Multiple parts reduce long-term maintenance costs Riveted staple remover Rivets Wide finger pad Wide tooth remover Spring Rivet Narrow tooth remover Narrow finger pad Figure 2. Staple Remover

Solution

2.1 Wide finger pad and wide tooth remover can be combined similiarly narrow pad and narrow tooth remover can be combined

2.2 least no of parts required are 4 i.e upper part, lower part spring and rivet

2.3 Spring and rivet are necesssary
