SIMPLE Calculator Program in EMU8086 - 8086 ASSEMBLY

The cheap calculator For this project, we will build a simple integer 4 function calculator. The functions will be addition, subtraction, multiplication and division. The project will be simplified by limiting the inputs to unsigned values less than or equal to 255. It will be possible to obtain sums greater than what fits into 8 bits, so that will have to be accounted for. Also, it will be possible to obtain differences that go negative. This will be accounted for. As for multiplication, we will see products that go into 16 bits. Division could yield a quotient with remainder in the 8 bit range In order to keep this project as simple as possible, we will make the following conditions: 1. Division will be limited to word divided by word operands. 2. Division will yield a quotient and remainder. Both must be displayed. No floating numbers 3. Multiplication will display up to 16 bit results, so you will need a 16 bit binary to ASCII conversion subroutine (Sound familiar?) 4. For negative values from subtraction, we will two\'s complement the result and print it with a minus sign in front of it. This will avoid the need for a special negative number conversion subroutine 5. For 9 bit sums, the low order 8 bits will go into AL, and the carry will be added into AH The standard 16 bit binary to ASCII conversion subroutine may be used on AX How to do this: Start with the dreaded flow chart. Write the program to read in values and then parse them Parse means to break something complex into simpler pieces. For example 147 202 There are 4 elements in this input, the first value, 147, the augend; an operation, plus; the second number, 202, the addend; and the final control character that will start the computation, the equal sign. We can use the spaces in the input as separators to help us break the input apart 1.You can use INT 21H, function 0AH to read in a string from the console. Point an index register, Sl or DI, to the start of the data. Remember, that start of data will be located at input + 2 2. Start reading bytes, one at a time from the input, transferring the bytes into a temporary memory buffer. When you hit the space, the first number has been read in. You may want

Solution

/   DATASG SEGMENT PARA \'Data\' 002 003     ques1 DB \"Enter the first number: $\" 004     ques2 DB \"Enter the second number: $\" 005     ques3 DB \"Enter the operation: $\" 006     num DW ? 007     num1 DW ? 008     ans DW ? 009       010     paralt label Byte 011     maxlen DB 4 012     actlen DB ? 013     dbdata DB 5 dup(\'$\') 014       015 016     DATASG ENDS 017 ;.............................................. 018     CODESG SEGMENT PARA \'Code\' 019     MAIN    PROC FAR 020         ASSUME SS:STACKSG, DS:DATASG, CS:CODESG 021         MOV AX,DATASG       ;Set address of data 022         MOV DS,AX       ;Segment in DS 023 024         mov ah, 02H     ;move cursor 025         mov bh, 0 026         mov dh, 9 027         mov dl, 20 028         Int 10H 029           030         mov ah, 09H 031         Lea DX, ques1 032         Int 21H 033           034         mov ah, 0AH ;for op1 035         Lea Dx, paralt 036         Int 21H 037           038         call con_num 039         Jmp Next 040           041     Next:   mov num, ax 042 043 044         mov ah, 02H     ;move cursor 045         mov bh, 0 046         mov dh, 11 047         mov dl, 20 048         Int 10H 049           050         mov ah, 09H 051         Lea DX, ques2 052         Int 21H 053           054         mov ah, 0AH ;op2 055         Lea Dx, paralt 056         Int 21H 057           058         call con_num 059         Jmp Next2 060 061     Next2: mov num1, ax 062 063 064         mov ah, 02H     ;move cursor 065         mov bh, 0 066         mov dh, 13 067         mov dl, 20 068         Int 10H 069 070         mov ah, 09H 071         Lea DX, ques3 072         Int 21H 073           074         mov ah, 0AH ;op3 075         Lea Dx, paralt 076         Int 21H 077 078         Lea Bx, dbdata 079         mov cl, [bx] 080         cmp cl, 2AH 081         JE Time 082         cmp cl, 2BH 083         JE Plus 084         cmp cl, 2DH 085         JE Min 086         cmp cl, 2FH 087         JE Divi 088 089     Time:   cmp num, 0 090         JL Inv 091         cmp num1, 0 092         JL Inv 093         mov ax, num 094         mul num1 095         mov ans, ax 096         Jmp Fin 097 098     Inv:    mov ax, num 099         imul num1 100         mov ans, ax 101         Jmp Fin 102 103     Plus:   mov ax, num 104         add ax, num1 105         mov ans, ax 106         Jmp Fin 107 108     Divi:   cmp num, 0 109         JL IDivi 110         cmp num1, 0 111         JL IDivi 112         mov ax, num 113         div num1 114         mov ans, ax 115         Jmp Fin 116       117     IDivi: mov ax, num 118         idiv num1 119         mov ans, ax 120         Jmp Fin 121 122     Min:    mov ax, num 123         sub ax, num1 124         mov ans, ax 125         Jmp Fin 126 127     Fin:    mov ah, 02H     ;move cursor 128         mov bh, 0 129         mov dh, 15 130         mov dl, 20 131         Int 10H 132 133         mov ah, 09H ;outputs user input 134         Lea Dx, dbdata 135         Int 21H 136 137       138 139 140 141     con_num Proc NEAR 142 143         push bx 144         push cx 145         push dx 146       147         Lea BX, dbdata 148         mov ax, 0 ;num 149         mov cx, 0 150         mov dl, 10 151           152     Keep:   mov cl, [bx] 153         cmp cl, 0DH 154         JE Done 155         sub cx, 30H 156         mul DL 157         add ax, cx 158         Jmp Keep 159 160     Done:   pop dx 161         pop cx 162         pop bx 163           164         ret 165         con_num Endp
