Consider the following system microprocessor based system Pr

Consider the following system microprocessor based system: Program the PLD such that interface memory chips at following starting addresses: Memory chip Starting address Ending address PLD Instruction (Program) Chip # 0 10000H Chip # 1 30000H Chip # 2 50000H Chip # 3 18000H Chip # 4 2F000H What is the capacity of each memory chip? How much total memory can you interface to the PLD? What is the MPU memory space?

Solution

MPU registers

..........................

Register	Address	NS Address Alias	Description
MPU_TYPE	0xE000ED90	0xE002ED90	MPU Type Register
MPU_CTRL	0xE000ED94	0xE002ED94	MPU Control Register
MPU_RNR	0xE000ED98	0xE002ED98	MPU Region Number Register
MPU_RBAR	0xE000ED9C	0xE002ED9C	MPU Region Base Address Register
MPU_RLAR	0xE000EDA0	0xE002EDA0	MPU Region Base Limit Register
MPU_RBAR_A1	0xE000EDA4	0xE002EDA4	MPU Region Base Address Register Alias 1
MPU_RBAR_A2	0xE000EDAC	0xE002EDAC	MPU Region Base Address Register Alias 2
MPU_RBAR_A3	0xE000EDB4	0xE002EDB4	MPU Region Base Address Register Alias 3
MPU_RLAR_A1	0xE000EDA8	0xE002EDA8	MPU Region Limit Address Register Alias 1
MPU_RLAR_A2	0xE000EDB0	0xE002EDB0	MPU Region Limit Address Register Alias 2
MPU_RLAR_A3	0xE000EDA8	0xE002EDB8	MPU Region Limit Address Register Alias 3
MPU_MAIR0	0xE000EDC0	0xE002EDC0	MPU Memory Attribute Indirection Register 0
MPU_MAIR0	0xE000EDC4	0xE002EDC4	MPU Memory Attribute Indirection Register 1
