Two cylinders are to be press-fitted together so that the principal stress with the greatest absolute value is not to exceed 60% of the yield strength of the material. Both members are made of a steel with a yield strength of 80 ksi, E = 30 times 10^6 psi, and v = 0.29. The nominal diameters of the cylinders are 1.0, 1.5, and 2.0 in. (a) Determine the maximum acceptable radial interference and the corresponding interface pressure, (b) For part (a), plot the stress distribution for each member, (c) If the assembly in part(a) is subjected to an internal pressure of 5000 psi, determine the resulting stress distribution in both members using the method of superposition. Plot your results.

Solution

The maximum possible radial interference is .057 mm.

The resulting stress is 56 mpa.
