How many brandies Branch a single twoterminal clement in a c

How many brandies? Branch: a single two-terminal clement in a circuit Segments of wire arc not counted as elements Examples: voltage source, resistor, current source

Solution

A branch represents a single element such as voltage source or a current source or a resistor.

We can say that a branch is two terminals of an element. The circuit figure shows 7 branches in the circuit. There is two sources one 10V voltage source, one 5mA current source, 5 resistors. As the circuit contains 7 elements so it has 7 branches. Every element has two terminals also.

ans: the circuit has 7 branches as it contains 7 elements.
