For the system shown in figure 2.1, directional relays are used at breakers CB2, CB4 and CBS .Over current relay is CB1. For a fault at F1 (bus1), what protective device detects the default? For a fault at F3 (bus3), what protective device detects the default ?

Solution

For a fault at bus 1.

If the fault ( line to earth / line to line ) causes a shortage of current then the over current relay works and detects the fault.

For a fault at F3… bus 3, depending on the distance from the fault location , the directional relays can get triggered.
