The following GUI is displayed once the application starts:
The suggested size of the GUI is 640x480.
There are 10 targets displayed with random x/y values within the following ranges:
Valid x values are between 40 and (width-40)
Valid y values are between 50 and 150.
No movement on the GUI is allowed until the user presses the “Down Arrow” key. Once the user presses the “Down Arrow” key, all the targets will slowly move to the bottom (x value must remain the same).
(I suggest slowing the targets down as they move towards the bottom to make the game more interesting. Instead of adding one to the y coordinate for each target every 0.025 seconds, add one-third instead).
A timer is also implemented and shown at the top of the GUI (Shown currently as Time: 0.000). As soon as the user presses the “Down Arrow” key, the timer will start and maintain the total time that the user has been playing the game in seconds. The precision of the timer should be to 3 decimal places (thousandths of a second)
Once the user presses the “Down Arrow” key, the user will also be able to move the cannon in the horizontal direction between the left (0) margin and the right (width -1) margin only using the following three options:
Pressing the “Right Arrow” key moves the cannon 5 pixels to the right
Pressing the “Left Arrow” key moves the cannon 5 pixels to the left
The user can drag the cannon by using the mouse to any horizontal position between 0 and width -1. (Must be implemented as a mouseDragged)
Once the user has positioned the cannon in the desired horizontal location, he can fire a cannonball from the cannon by pressing the “Up Arrow” key.
Firing the cannon consists of displaying a cannonball on the screen at the end of the cannon barrel and gradually moving the cannonball upward (vertical direction only) towards the desired target. The cannonball image is given as cannonball.png and is shown below:
An example of initially displaying the cannonball upon pressing the “Up Arrow” key at the end of the cannon barrel is shown below:
The cannonball should move upward gradually (between 1 to 5 pixels every .025 seconds) from the cannon barrel as shown below:
The cannonball continues to move upward until it either :
Hits a target
Reaches the upward boundary
An example of the cannonball missing a target and travelling to the top boundary is shown below:
The following should be performed if the cannonball hits a target:
Remove the target from the screen
Remove the cannonball from the screen (only one target can be hit by a single cannonball)
Assume that only one cannonball can be on the screen at a time. (You should prevent the cannon from firing while a cannonball is still visible on the display)
Each time a cannonball is fired, the shot information is incremented by 1 and displayed at the top of the display.
Each time a target is hit, the score information is incremented by 1 and displayed at the top of the display.
A mosaic illustrating the playing of the game is shown below:
The game continues until either:
All targets are hit (i.e., score is 10)
All targets have moved beneath the bottom border and are no longer visible
Once the game is completed, the user can restart the game by pressing:
“Down Arrow” key
The targets will be placed at random locations and the timer will begin immediately.
Solution
import java.awt.BorderLayout;
import java.awt.Color;
import java.awt.FlowLayout;
import java.awt.Graphics;
import java.awt.GridLayout;
import java.awt.Image;
import java.awt.Toolkit;
import java.awt.event.KeyEvent;
import java.awt.event.KeyListener;
import java.awt.event.MouseAdapter;
import java.awt.event.MouseEvent;
import java.awt.event.MouseMotionAdapter;
import java.io.File;
import java.io.IOException;
import javax.imageio.ImageIO;
import javax.swing.JFrame;
import javax.swing.JLabel;
import javax.swing.JPanel;
import java.util.Random;
import java.util.Timer;
import java.util.TimerTask;
public class SpaceInvaders extends JFrame
{
private int score = -1; //Vars for labels and creation of labels
private int targetsHit = 0;
private int shots = 0;
private JLabel timerLabel = new JLabel(\"Time: \");
private JLabel shotCounter = new JLabel(\"Shots: \" + shots);
private JLabel scoreLabel = new JLabel(\"Score: \" + score + \" - Targets Hit: \" + targetsHit);
private JLabel updateLabel = new JLabel(\"Press Down to Start\");
private Image backgroundImage; //Image vars to hold all required images
private Image cannon;
private Image cannonBall;
private Image target;
private gamePanel gp;
private int cannonXAxis = 300; //Vars for control of movement on screen
private int cannonYAxis = 418;
private int cBallXAxis = 316;
private int cBallYAxis = 416;
private int cBallYHome = 416;
private int x_offset;
private int x_offsetCBALL;
private boolean[] targetHit = new boolean[10];
private int[][] targetCoord = new int [10][2];
private int targetsMissed = 0;
private Timer timer1;
private TimerTask tf;
boolean pic_touched = false;
private long tStartMilli; //Vars for time control
private long tEndMilli;
private long tElapsedMilli;
private long finalTime;
public SpaceInvaders()
{
try{ //Read in images used
backgroundImage = ImageIO.read(new File(\"src/program7/bg2.png\"));
cannon = ImageIO.read(new File(\"src/program7/cannon1.png\"));
cannonBall = ImageIO.read(new File(\"src/program7/cannonBall.png\"));
target = ImageIO.read(new File(\"src/program7/target.png\"));
} catch (IOException e){e.printStackTrace();}
for (int i = 0; i < 10; i++) //Initialize all targets hit to not show
targetHit[i] = true;
keylistener keyListener = new keylistener(); //Initial KeyListener
MouseHandler mh = new MouseHandler(); //Initial MouseListener
MouseClickedHandler mch = new MouseClickedHandler(); //Initial MouseClick
gp = new gamePanel(); //Initial panel
gp.addMouseMotionListener(mh); //Add MouseMotionListener
gp.addMouseListener(mch); //Add MouseListener
gp.addKeyListener(keyListener); //Add KeyListener
gp.setFocusable(true); //Request Focus for Events
timer1 = new java.util.Timer();
tf = new TimerFired();
timer1.scheduleAtFixedRate( tf, 0, 65);
gp.setLayout(new FlowLayout());
gp.add(timerLabel);
gp.add(scoreLabel);
gp.add(shotCounter);
gp.add(updateLabel);
this.add(gp);
this.setResizable(false);
this.setDefaultCloseOperation(this.EXIT_ON_CLOSE);
this.setSize(640,480);
this.setVisible(true);
}
//=============================================================
class gamePanel extends JPanel implements Runnable
{
public void run()
{
try {
repaint();
} catch(Exception e){
e.printStackTrace();}
}
public void paintComponent(Graphics g)
{
super.paintComponents(g);
g.drawImage(backgroundImage, 0, 0, this);
g.drawImage(cannon,cannonXAxis, cannonYAxis, this);
g.drawImage(cannonBall, cBallXAxis, cBallYAxis, this);
for (int r = 0; r < 10; r++)
{
if (targetHit[r] == false)
g.drawImage(target, targetCoord[r][0] , targetCoord[r][1], this);
}
tEndMilli = System.currentTimeMillis();
tElapsedMilli = (tEndMilli - tStartMilli);
timerLabel.setText(\"Time: \" + tElapsedMilli/1000.0);
if (score == 10)
{
finalTime = (long) (tElapsedMilli/1e3);
timerLabel.setText(\"Time: \" + finalTime);
}
if (score == -1)
{
timerLabel.setText(\"Time: \" + 0);
}
}
}
//=============================================================
public static void main(String[] args)
{
SpaceInvaders si = new SpaceInvaders();
}
//=============================================================
class keylistener implements KeyListener
{
@Override
public void keyTyped(KeyEvent e){}
@Override
public void keyPressed(KeyEvent e)
{
//38 UP //40 //37 //39 RIGHT
if (e.getKeyCode() == 37) //Left Arrow key, move Cannon // -- LEFT --
{
cannonXAxis = cannonXAxis - 5; //Move Cannon left 5 pixels
if (cBallYAxis == 416) //IF cBall is home move with cannon. Otherwise let it stay on path
{
cBallXAxis = cBallXAxis - 5;//Move cBall left 5 pixels
}
}
if (e.getKeyCode() == 39) //Right Arrow key, move Cannon // -- RIGHT --
{
cannonXAxis = cannonXAxis + 5; //Move Cannon Right 5 pixels
if (cBallYAxis == 416) //If Cball is home move with cannon.
{
cBallXAxis = cBallXAxis + 5;//Move cBall right 5 pixels
}
}
if (e.getKeyCode() == 38 && cBallYAxis == 416) //Up arrow, shoot cBall // -- UP --
{
cBallYAxis = 415;
shots = shots + 1;
shotCounter.setText(\"Shots: \" + shots);
}
if (e.getKeyCode() == 40 && cBallYAxis == 416) //Key ID for Arrow Down // -- DOWN --
{
Random ran = new Random();
for (int r = 0; r < 10; r++) //Random X Coord generator
{
targetCoord[r][0] = ran.nextInt(610);
targetHit[r] = false;
}
for (int c = 0; c < 10; c++) //Random Y Coord generator
{
targetCoord[c][1] = ran.nextInt(250);
}
cannonXAxis = 300; //Reset\'s EVERYTHING on Down Arrow Press
cannonYAxis = 418;
cBallXAxis = 316;
cBallYAxis = cBallYHome;
score = 0;
shots = 0;
targetsMissed = 0;
targetsHit = 0;
shotCounter.setText(\"Shots: \" + shots);
scoreLabel.setText(\"Score: \" + score + \" - Targets Hit: \" + targetsHit);
timerLabel.setText(\" Time: \" + 0 + \"\");
updateLabel.setText(\"\");
tStartMilli = System.currentTimeMillis();
for (int i = 0; i < 10; i++)
targetHit[i] = false; //All targets not Hit
}
repaint();
}
//=============================================================
@Override
public void keyReleased(KeyEvent e){}
};
public class TimerFired extends TimerTask implements Runnable
{
@Override
public void run()
{
if (cBallYAxis <= 415) //If CBall is at home and fired
{
cBallYAxis = cBallYAxis - 5; //Move upwards 5 pixels every TimerFired
}
if ( cBallYAxis < 2) //If off screen, reset to resting position
{
cBallYAxis = 416;
cBallXAxis = cannonXAxis + 16;
}
for (int i = 0; i < 10; i++) //Loop through all targets
{
targetCoord[i][1] = targetCoord[i][1] + 1; //Move Target down 1 pixel
if (targetCoord[i][1] > 480) //If Dropped below screen
{
targetsMissed = targetsMissed + 1;
if (targetsMissed >= 2) //If 2 targets have been missed
{ //Runs down Arrow Code to reset
cannonXAxis = 300;
cannonYAxis = 418;
cBallXAxis = 316;
cBallYAxis = cBallYHome;
score = 0;
shots = 0;
shotCounter.setText(\"Shots: \" + shots);
scoreLabel.setText(\"Score: \" + score + \" - Targets Hit: \" + targetsHit);
timerLabel.setText(\" Time: \" + 0 + \"\");
updateLabel.setText(\"GAME LOST. You missed too many targets\");
for (int w = 0; w < 10; w++)
targetHit[w] = false;
}
}
if (cBallXAxis < targetCoord[i][0] + 40 && cBallXAxis > targetCoord[i][0]) //Checking for Collision
{ //Checks for X Coord
if (cBallYAxis - 30 < targetCoord[i][1]) //Checks for Y Coord
{
targetHit[i] = true;
targetCoord[i][0] = 0; //move Target off screen so it may not be hit again.
targetCoord[i][1] = -2000;
score = score + 1; //Update everything else
targetsHit = targetsHit + 1;
scoreLabel.setText(\"Score: \" + score + \" - Targets Hit: \" + targetsHit);
cBallXAxis = cannonXAxis + 16;
cBallYAxis = cBallYHome;
}
}
}
repaint();
if (score == 10)
{
updateLabel.setText(\"CONGRATULATIONS YOU WON! Down Arrow to Restart\");
}
}
}
//=============================================================
class MouseClickedHandler extends MouseAdapter
{
public void mousePressed(MouseEvent me)
{
if ( (me.getX() > cannonXAxis) && (me.getX() < cannonXAxis + 40) && (me.getY() > cannonYAxis) && (me.getY() < cannonYAxis + 40))
{
pic_touched = true;
x_offset = me.getX() - cannonXAxis;
x_offsetCBALL = me.getX() - cBallXAxis;
}
else
{
pic_touched = false;
}
}
}
//=============================================================
class MouseHandler extends MouseMotionAdapter
{
public void mouseDragged(MouseEvent e)
{
if (pic_touched)
{
cannonXAxis = e.getX() - x_offset;
if (cBallYAxis == 416)
{
cBallXAxis = e.getX() - x_offsetCBALL;
}
}
repaint();
}
}
}
