The figure below is a squarelaw modulator the signal present

The figure below is a square-law modulator the signal presented to the nonlinear device is represented by v_2 = a_1 v_1 (t) + a_2 v^2 1(t) where a_1 and a_2: are constants, v_1 (t) is the input voltage, and v_2 (t) is the output voltage. The input voltage is defined by v_1 (t) = A_c Cos(2pi f_c t) + m(t) where m(t) is the message signal and A_c Cos(2pi fct) is the carrier wave. Evaluate the output voltage v_2(t). Specify the frequency response that the tuned must satisfy in order to generate an AM signal with f_c as the carrier.

Solution

https://www.dropbox.com/s/7gdsrifprq8gnyr/259.bmp?dl=0
