your IMPORTANT: Put your name on your \"equations\" sheet and hand it in with exam. If you do not provide an equations sheet, you will receive a \"o for your exam score. Include Proper Units in Your Answers 1 ksi=1 ,000psi, 1 mm2=104m2 1 m-100cm=103mmm; 1GPa=10spa; 1KN#1ON: 1 Mg=1 06g-103kg: 1 kip#1 ,000lb. 1) (5 points) A 100-mm long rod has a diameter of 15 mm. An axial force of 10 KN is applied as shown. Assume that E = 70 GPa (70x109 Pa) and u :0.35. 10 kN 100 mm 15 mm 10 kN J AL a) (2 points) Determine the change in length of the rod. 76 X1 6810-21.vi G

Solution

Change in length = PL/AE

Where P = load

L= length

A= area

E = elastic modulus

Change in length = (10*1000*100)/(176.71*70*1000)

=0.081 mm
