Beginning from power on, the following byte-addressed cache references are recorded.

For EACH reference, list (1) its tag, index, and offset, (2) whether it is a hit or a miss, and (3) which bytes were replaced (if any).

Address

Hex	00	04	10	84	E8	A0	400	1E	8C	C1C	84	884
Dec	0	4	16	132	232	160	1024	30	140	3100	180	2180

Solution

If the cache block been searched by the CPU is matched with an existing block in the cache, it is called a cache hit. But if the CPU cannot locate the cache block, it’s a cache miss.

After a successful hit if a particular cache block is called again it becomes a technical cache miss, as the block is then replaced.

The following table shows the cache block replacement occurs in this case.

The sequence of 32-bit memory references is shown as:

  0, 4, 16, 132, 232, 160, 1024, 30, 140, 3100, 180, 2180:

Address Reference

Binary Address

Hit / Miss

Assigned cache block

Replaced Bytes.

0

000000000000

Miss

0000

NO

4

000000000100

Hit

0100

NO

16

000000010000

Miss

0000

NO

132

000010000100

Miss

0100

NO

232

000011101000

Miss

1000

NO

160

000010100000

Miss

0000

NO

1024

010000000000

Miss

0000

YES

30

000000011110

Hit

1110

NO

140

000010001100

Hit

1100

NO

3100

110000011100

Miss

1100

YES

180

000010110100

Miss

0100

NO

2180

100010000100

Miss

0100

YES

The table shows that the Number of replaced blocks is 3.

Index

0000

0001

0010

0011

0100

0101

0110

0111

Contents

M(160)

M(2180)

M(140)

Address Reference	Binary Address	Hit / Miss	Assigned cache block	Replaced Bytes.
0	000000000000	Miss	0000	NO
4	000000000100	Hit	0100	NO
16	000000010000	Miss	0000	NO
132	000010000100	Miss	0100	NO
232	000011101000	Miss	1000	NO
160	000010100000	Miss	0000	NO
1024	010000000000	Miss	0000	YES
30	000000011110	Hit	1110	NO
140	000010001100	Hit	1100	NO
3100	110000011100	Miss	1100	YES
180	000010110100	Miss	0100	NO
2180	100010000100	Miss	0100	YES
