In the beam connection shown below, the beam reaction is transferred to the column through

A. Angle A and Bolts C and D

B. Angle B and Bolt F

C. Angle A and B and Bolts C and F

D. Angle B and Bolt E

The experts say the question needs more information, but this is 100% of the question and information given by the professor. Please expand on what information you need yet. Thank you.

STEEL COLUMN BOLTS C BOLTS D STEEL BeN BOLTS ANGLE BOLTS F

Solution

From the figure, clearly it is (an unstiffened) bolted top and seat connection. Here, the top angle only provides lateral support (prevents beam from accidental rotations). And, design of this connection generally is based on the assumption that the seat angle carries the full beam reaction.

Beam shear is transferred to column in the form of of end reaction (vertical). Hence, answer for your question is (B) Angle B and Bolt F
