Circle the correct answer. (a) Name terminal (i), region (ii), and region (iii) of the NMOS in Figure PR-1.

Solution

A) There are three modes of operation in nmos

i)triode ii) cutoff iii) saturation

B) If Vt<Vdc<Vov then the nmos is in triode mode.

c) Channel length modulation occurs in saturation mode

D) early voltagedepends on width of the channel and temperature
