Solution
1. From given phasor diagram current is more than voltage and also leads the applied voltage by some angle \\theta.
2. In both \"a and d\" current lags applied voltage.
3. In both \"b and c\" current leads applied voltage.
4. In both \"a and c\" current more than applied voltage (magnitude).
From points both 3 and 4 option \"c\" wave form matches the given phasor diagram.
