Using MATLAB specify the minimum number of elements and plot

Recall that famous Fibonacci sequence is composed of elements created by adding the two previous elements. One interesting property of a Fibonacci sequence is that the ratio of the values of adjacent members of the sequence approaches a number called \"the golden ratio\" or Phi (phi). Create a program, which determines the minimum number of elements in the Fibonacci sequence needed to bring error in estimating Phi below 0.001

Solution

Fibonacci series code.

%code
f=[1 1];
x=1;
while f(x) < 1000
f(x+2)=f(x+1)+f(x);
f_ratio(x+2)= f(x+2)/f(x+1);
D_ratio(x+2)=f_ratio(x+2)-f_ratio(x+1);
if D_ratio<=0.001
break
else x=x+1;
end
end
f %%fibanocci series
plot(f_ratio,\'b\');
hold on;
plot(D_ratio,\'r\')
grid On;
disp(\'element at which fibanocci ratio becomes 0.001 is\')
x

Command window result:

>> Fibanocci_golden_ratio_convergence

f =

Columns 1 through 7

1 1 2 3 5 8 13

Columns 8 through 14

21 34 55 89 144 233 377

Columns 15 through 18

610 987 1597 2584

element at which fibanocci ratio becomes 0.001 is

x =

17

>>
