In the case f Figure 6 determine the moment of the force ab

In the case (f) (Figure 6) , determine the moment of the force about point O.

« previous 5 of 9 next >» Preliminary Problem 4.1 Part F In the case (f) (Figure 6), determine the moment of the force about point C. Suppose that F1200 N and F2600 N Express your answer to three significant figures and include the appropriate units. Enter positive value if the moment is counterclockwise and negative value if the moment is clockwise. 1200 N·m Submit My Answers Give Up Figure 6 of 9 Incorrect; Try Again; 5 attempts remaining Part G In the case (g) (Figure 7), determine the moment of the force about point O Express your answer to three significant figures and include the appropriate units. Enter positive value if the moment is counterclockwise and negative value if the moment is clockwise. Mo= 1080 N·m Submit My Answers Give Up

Solution

for part f answer must be zero.. there is no perpendicular distance between o and the point where force is applied..

Mo= 200*0=0n-m
