Question 16

A K-F flip-flop works as follows. If KF=00, the next state is 1. If KF=01, the next state is the same as the present state. For KF=10, the next state is the complement of the present state. When KF=11, the next state is 0. (note: I have changed it slightly from the problem we did in class!)

Complete the table with KF inputs needed for the various state changes. Use don\'t cares whenever possible!!

Q Q⁺ K    F

0 0

0 1

1 0

1 1

For present state 0 and next state 1, what is the best input for F?

A.

1

B.

0

C.

X

D.

None of these

Question 17

A K-F flip-flop works as follows. If KF=00, the next state is 1. If KF=01, the next state is the same as the present state. For KF=10, the next state is the complement of the present state. When KF=11, the next state is 0. (note: I have changed it slightly from the problem we did in class!)

Complete the table with KF inputs needed for the various state changes. Use don\'t cares whenever possible!!

Q Q⁺ K    F

0 0

0 1

1 0

1 1

For present state 1 and next state 0, what is the best input for K?

A.

1

B.

None of these

C.

0

D.

X

Question 18

A K-F flip-flop works as follows. If KF=00, the next state is 1. If KF=01, the next state is the same as the present state. For KF=10, the next state is the complement of the present state. When KF=11, the next state is 0. (note: I have changed it slightly from the problem we did in class!)

Complete the table with KF inputs needed for the various state changes. Use don\'t cares whenever possible!!

Q Q⁺ K    F

0 0

0 1

1 0

1 1

For present state 1 and next state 0, what is the best input for F?

A.

0

B.

1

C.

X

D.

None of these

Question 19

A K-F flip-flop works as follows. If KF=00, the next state is 1. If KF=01, the next state is the same as the present state. For KF=10, the next state is the complement of the present state. When KF=11, the next state is 0. (note: I have changed it slightly from the problem we did in class!)

Complete the table with KF inputs needed for the various state changes. Use don\'t cares whenever possible!!

Q Q⁺ K    F

0 0

0 1

1 0

1 1

For present state 1 and next state 1, what is the best input for K?

A.

None of these

B.

1

C.

0

D.

X

Question 20

A K-F flip-flop works as follows. If KF=00, the next state is 1. If KF=01, the next state is the same as the present state. For KF=10, the next state is the complement of the present state. When KF=11, the next state is 0. (note: I have changed it slightly from the problem we did in class!)

Complete the table with KF inputs needed for the various state changes. Use don\'t cares whenever possible!!

Q Q⁺ K    F

0 0

0 1

1 0

1 1

For present state 1 and next state 1, what is the best input for F?

A.

X

B.

0

C.

1

D.

None of these

	A.	1
	B.	0
	C.	X
	D.	None of these

Solution

16)B

17)C

18)C

19)C

20)A
