The dc/dc converter of the figure shown below takes in an input voltage V_1 and generates an output current I_2. What is the voltage conversion ratio V_0/V_s for this converter assuming periodic steady-state continuous conduction mode operation? [Select the one best answer from the choices given below] V_0/V_1 = D/1 - D V_0/V_z = 1/1 - D V_0/V_z = D V_0/V_2 = (1 - D)/D V_0/V_z = 1 - D V_0/V_z = 1/D V_0/V_z = -D/1 - D V_0/V_z = -1/1 - D V_0/V_z = -D V_0/V_z = (1 -- D)/D V_0/V_z = -(1 - D) V_0/V_z = -1/D

Solution

the operation is same as the cuk converter with little modification.. but output you will get same output.

so most appropriate answer is \'a\'
