Problem 2. Given the following, draw the figure below: Set drawing units to Architectural Srt drawing limits to 8-1/2,11 Set GRIDDISPLAY to 0 Set grid to 1/4inches Set snap to 1/8\" Layers are up to you.

Solution

The commands for setting up the sheet are

1. Type UNITS and set to Architectural

2. Type LIMITS and set it to 8-1/2,11

3. Type GRIDDISPLAY and set it to 0

4. Type GRID and set to 1/4 in

5. Type SNAP and set to 1/8 in

Door dimensions are not given, which is required to plot the drawing.

For doing the Curvy shape use the command \"FILLET\" and then give the value of the radius.
