Solution

% matlab code for rador

clc;
clear all;
%Customize graph
figure(\'units\',\'normalized\',\'outerposition\',[0 0 1 1]);
whitebg(\'black\');
%Draw Scale Data
th = linspace(0,pi,1000);
R = 10:10:100;
for i=1:length(R);
x = R(i)*cos(th);
y = R(i)*sin(th);
plot(x,y,\'Color\', [0.603922 , 0.803922 , 0.196078] ,\'LineWidth\',1);
hold on;
end
%Draw Axis data
x0 = [0 100 0 0 0 0 ]; x1 = [0 100 86.60 50 -50 -86.60]; y0 = [0 0 0 0 0 0]; y1 = [100 0 50 86.60 86.60 50];
for i=1:length(x0);
hold on;
plot([x0(i),x1(i)],[y0(i),y1(i)] ,\'Color\', [0.603922 , 0.803922 , 0.196078],\'LineWidth\',2);
end
%Draw Sonar default data
for i=1:180
hold on;
[x, y] = pol2cart(i*0.0174532925, 100);
h(i) = plot([0,x],[0,y],\'g\',\'LineWidth\',1);
end
%define serial port
s1 = serial(\'COM12\');
s1.BaudRate=9600;
fopen(s1);
%Draw Sonar Data
while(1)
data = fscanf(s1);
[th, r] = strtok(data);
th = real(str2num(th));
r = str2num(r);
set(h(th),\'color\',\'r\');
[x0, y0] = pol2cart(th*0.0174532925, 100);
[x, y] = pol2cart(th*0.0174532925, r);
set(h(th),\'XData\',[x0,x]);
set(h(th),\'YData\',[y0,y]);
m = plot([0,x0],[0,y0],\'r\',\'LineWidth\',3);
drawnow
delete(m);
end
fclose(s1);

clc;

clear all;

%Customize graph

figure(\'units\',\'normalized\',\'outerposition\',[0 0 1 1]);

whitebg(\'black\');

%Draw Scale Data

th = linspace(0,pi,1000);

R = 10:10:100;

for i=1:length(R);

x = R(i)*cos(th);

y = R(i)*sin(th);

plot(x,y,\'Color\', [0.603922 , 0.803922 , 0.196078] ,\'LineWidth\',1);

hold on;

end

%Draw Axis data

x0 = [0 100 0 0 0 0 ]; x1 = [0 100 86.60 50 -50 -86.60]; y0 = [0 0 0 0 0 0]; y1 = [100 0 50 86.60 86.60 50];

for i=1:length(x0);

hold on;

plot([x0(i),x1(i)],[y0(i),y1(i)] ,\'Color\', [0.603922 , 0.803922 , 0.196078],\'LineWidth\',2);

end

%Draw Sonar default data

for i=1:180

hold on;

[x, y] = pol2cart(i*0.0174532925, 100);

h(i) = plot([0,x],[0,y],\'g\',\'LineWidth\',1);

end

%define serial port

s1 = serial(\'COM12\');

s1.BaudRate=9600;

fopen(s1);

%Draw Sonar Data

while(1)

data = fscanf(s1);

[th, r] = strtok(data);

th = real(str2num(th));

r = str2num(r);

set(h(th),\'color\',\'r\');

[x0, y0] = pol2cart(th*0.0174532925, 100);

[x, y] = pol2cart(th*0.0174532925, r);

set(h(th),\'XData\',[x0,x]);

set(h(th),\'YData\',[y0,y]);

m = plot([0,x0],[0,y0],\'r\',\'LineWidth\',3);

drawnow

delete(m);

end

fclose(s1);

% matlab code for rador object to rotate 30 degrees around x-axis

direction=[1 0 0];

rotate(rador,direction,30)

% matlab code for rador object to rotate 30 degrees sround y-axis

direction=[ 0 1 0];

rotate(rador,direction,30)
