Problem 3312 The loop in the figure is being pushed into the

Problem 33.12 The loop in the figure is being pushed into the 0.10 T magnetic field at 50 m/s . The resistance of the loop is 0.60 5.0 cm Part A What is the magnitude of the current in the loop? Express your answer with the appropriate units. alue Units Submit atue My Answers Give Up Part B What is the direction of the current in the loop? Submit My Answers Give Up nue

Solution

E = B L v = 0.10 * 5 * 10^-2 * 50

= 0.25 V

I = E / R = 0.25 / 0.60

= 0.417 A

To oppose the change in the magnetic field, the magnetic field produced by the induced current will be created by a current going clockwise
