Fill in the blanks for the source and destination IP address

Fill in the blanks for the source and destination IP addresses, as well as the source and destination MAC addresses at both the source and the destination, for a frame traveling from Station A to Station D in the network through router R2.

Solution

Answer:

Frame from A to D

The source IP address is going to be A and the destination IP address is going to be D. so

Source IP = A’s IP address

Destination IP = D’s IP address

Source MAC = A’s MAC address

Destination MAC = C’s MAC address

In this when A sending data to the other host it will first determines that the destination host is on the local network. After analysing if the destination host is not in local .Then A sends to its configured default gateway which is C.
