Observe the two stress distribution plots below, what is the difference between the two plots?

Answer :

Diffrence between two stress distibution :

Take left side stress distribution as figure 1 and right side stress distribution as figure 2.

1. In figure 1 Stress distributin is less and in figure 2 stress distribution is large.

2. In figure 1 stress distribution is compressed and in figure 2 stress distribution stress distibution is expanded.

3. In figure 1 stress distribution is less at corners and in figure 2 stress distribution is large at corners.

4. In figure 1 stress distribution is small exist at left side portion and in figure 2 stress distribution is predominent.

5. In figure 1 stress distribution is absence at right portion and in figure 2 stress distribution is exist at right portion.

6. In figure 1 stress distribution is average value and in figure 2 stress distribution is critical.

7. In figure 1 loading is less and in figure 2 loading is high.

8. In figure 1 impact load is not exist and in figure 2 impact load is exist.

9. In figure 1 ductile material is exist and in figure 2 brittle material is exist.

10. In figure 1 material is not fail and in figure 2 material is fail.

11. In figure 1 stress distribution is upto yield point and in figure 2 stress distribution is upto ultimate point.
