Write pseudocode for the following Given a stack and a queue

Write pseudocode for the following:

Given a stack and a queue, write a function that calls existing stack/queue functions to check if they contain the same data (top of the stack must be identical to the front of the queue, etc.)

Solution

#include<stdio.h>
#include<process.h>
#include<malloc.h>
int Qarr[50], noq, Front = -1, Rear = -1;
struct mystack
{
int no;
struct mystack *next;
}*top = NULL;

typedef struct mystack st;

//Add dat to stack
void push( )
{
st *p;
p = (st *) malloc(sizeof(st));
printf(\"\ Enter the number \");
scanf(\"%d\", &p -> no);
p -> next = top;
top = p;
}

//Remove data from stack
int pop( )
{
st *p;   p = top;
if(top == NULL)
    printf(\"\ Stack Underflow\");
else
{
    top = top -> next;
return (p -> no);
}
}

//Display data from stack
void dispS()
{
st *p;   p = top;
while(p != NULL)
{
   printf(\"\ no = %d\", p -> no);
p = p -> next;
}
}

//Add data to Queue

void Que_Ins( )
{
int Item;
if(Rear < noq-1)
{
printf(\"\ Enter a number \");
scanf(\"%d\", &Item);
if(Front == -1)
Front = Rear = 0;
else
Rear++;
Qarr[Rear] = Item;
}
else
{
printf(\"\ Queue OVERFLOW \ \");
exit(0);
}
}

//Display data from queue
void dispQ( )
{
int c;
printf(\"\ QUEUE Contents \ \");
for(c = 0; c < noq; c++)
printf(\" |Q[%d]| = %3d \", c+1, Qarr[c]);
}

//Remove data from queue
int Que_Del( )
{
int val;
if(Front != -1)
{
val = Qarr[Front];
if(Front == Rear)
Front = Rear = -1;
else
Front++;
printf(\"\ Deleted Item = %d \", val );
printf(\"Front= %d Rear= %d\", Front, Rear);
return val;
}
else
printf(\"\ Stack UNDERFLOW \ \");
}

void main( )
{
int c, f = 0, nos, items, itemq;
printf(\"\ Enter How many Elements need for Stack\");
scanf(\"%d\",&nos);
for(c = 0; c < nos; c++)
push();
printf(\"\ Enter How many Elements need for Queue\");
scanf(\"%d\",&noq);
for(c = 0; c < noq; c++)
Que_Ins();
if(nos != noq)
{
printf(\"\ Not Identical \");
}
dispS();
dispQ();
for(c = 0; c < nos; c++)
{
items = pop();
itemq = Que_Del();
if(items != itemq)
{
f = 1;
break;
}
}
if(f == 1)
printf(\"\ Not Identical\");
else
printf(\"\ Identical\");
}

Output 1:

Enter How many Elements need for Stack3

Enter the number 10

Enter the number 20

Enter the number 30

Enter How many Elements need for Queue3

Enter a number 30

Enter a number 20

Enter a number 10

no = 30
no = 20
no = 10
QUEUE Contents
|Q[1]| = 30 |Q[2]| = 20 |Q[3]| = 10
Deleted Item = 30 Front= 1 Rear= 2
Deleted Item = 20 Front= 2 Rear= 2
Deleted Item = 10 Front= -1 Rear= -1
Identical

Output 2:

Enter How many Elements need for Stack3

Enter the number 10

Enter the number 20

Enter the number 30

Enter How many Elements need for Queue3

Enter a number 30

Enter a number 10

Enter a number 20

no = 30
no = 20
no = 10
QUEUE Contents
|Q[1]| = 30 |Q[2]| = 10 |Q[3]| = 20
Deleted Item = 30 Front= 1 Rear= 2
Deleted Item = 10 Front= 2 Rear= 2
Not Identical
