Define a solid model and briefly discuss its role and applic

Define a solid model and briefly discuss its role and applications in modem mechanical engineering. As chief project engineer you are to design an adult bicep exercise machine. Using a Morphological Ideation Chart, list at least five attributes necessary for the design and suggest alternate ideas for each attribute. Accompany the chart with any other supporting documentation.

Solution

Answer 3 a) Solid Model: It is a type of process to represent an object more completely than its wire frame model. In addition to geometrical information it also adds topological information and this helps to represent any solid object more unambigously. Role and applications in modern Mechanical Engineering: CAD is the backbone of modern mechanical engineering. Solid modelling is the most important part of CAD software. By applying solid modelling in CAD, viewers are able to view the design object same as real manufacturing object. It helps to view the object from different plane and direction. This gives confidence to a design engineer as they are able to see the object as they wanted to. It also gives idea to a design engineer about the changes can be made in design as per requirements.

Beside this solid modelling is also used in animation industry to create various characters and medical industry to visualize different tissues of the body, designing of various medical devices etc.

Answer 3 b) Step 1. Identify the needs of customer.

Step 2. Establish the target specification.

Step 3. Analysis of running and competitive product.

Step 4. Generation of product concepts.

Step 5. Selection of product concept.

Step 6. Refine product specifications.

Step 7. Peromance of economic analysis.

Step 8. Planning of remaining development project.
