Which configuration is shown in the figure a Quarter bridge

Which configuration is shown in the figure? a. Quarter bridge b. Half bridge c. Full bridge d. Wheatstone bridge 16. What is 1000 microstrain? a. 1% b. 0.1 c. 0.1% d. 0.01 17. How many wires are used in a thermocouple a.1 b. 2 c. 3 d. Depends on the thermocouple type 18. What is CJC in a thermocouple a. Provides a reference temperature b. Provides a completion resistor c. Make the connection secure d. None of the above 19. What is the basis of how thermocouples work a. Change of resistance because of temperature difference b. Change of voltage because of temperature difference c. Infra-red radiation of the object d. Heat conduction 20. A thermocouple is held initially at Temperature T_1 = 100 deg C and at time is exposed to stationary air at romm temperature. What happens to the temperature measured a. Increases based on free convection b. Decreases based on free convection c. Increases based on forced convection d. Decreases based on forced convection 21. What temperature s

Solution

15 - d

16 - c = 1000 x 10^-6 x 100% = 0.1%

17 - b

18 - a

19 - b

21 - a
