Thevenins theorem provides a method for simplifying complex

Thevenin\'s theorem provides a method for: simplifying complex series-period circuits. building complex parallel circuits despising complex series-parallel circuits. all of these. According to the maximum power transfer theorem, maximum power is delivered to load when the load resistance is at load twice or more than source less than one-half of the source resistance. larger than source resistance exactly equal to the source resistance. If the cross-sectional are of a magnetic field decreases, the flux density increase remains the same decrease A is a type of electromagnetic device than has a movable from core called a plunger. speaker solenoid analog meter Which of the following can be measured from points B to F in Figure 8-1? the period the peak-to-peak voltage the frequency the angle A sine wave\'s instantaneous voltage is 0 V at degrees. 0 360 180 all of these

Solution

1. Answer is option a)

Thevinin\'s theorom provides a method for simplifying a complex series parallel circuit.

2. Answer is option D)

According to maximum power transfer theorom, maximum power is delivered to any load when the load resistance is exactly equal to that of source reistance.

3. Answer is option A)

If the cross sectional area of magnetic field decreases , the magnetic flux density increases.

4. Answer is option D)

A relay is a type of electromagentic device that has a movable iron core called a plunger.

5. Answer is option A)

The period can be inferred from the points B and F in the figure.

5. Answer is option D)

Sine wave instantaneous voltages is zero at 0,180,360
