For the hydraulic lift case shown calculate the required input force F1 (Newtons) and resulting output displacement x2 (mm).

Solution

Solution: As per Pascal\'s law the pressure is transmitted equally in both directions. This concept is used in Hydraulic lift as is shown in figure.

F1/ d1²= F2 /d2^{2 (Please don\'t confuse between F1 & F2 given in the question)}

^{As per question:}

^{5000 N/(0.15 m)*(0.15m) = F2 ( we have to find out)/(0.03m)*(0.03m)}

^{F2= 200 N Answer.....}

2nd part: We have to find out the displacement:

F1*x1= F2*x2

5000 N*x2 (we have to find out)= 200 N*0.03

x2= 1.2 mm Answer......
