In the Bar Chart below what is the status of activity B at the end of month 2? Work Item Months Work completed at end of month 2 Work completed at end of month 3 On time head of schedule hind the scheule not be assesed from the bar chart

Solution

yellow colour shows the amount of work that has been completed and green represent the work completed in month 3.

For activity B, if u look at the time (i.e., x=2), the yellow colour is behind the x=2 month mark, hence it was running behind schedule but at end of 3rd month yellow colour did the lagging behind work of month 2 and the work to be done in month 3 to complete activity on time.

Hence answer would be at end of month 2, activity B was running behind schedule.

Hope you understood.

Have a nice day

(thumbs up please)
