CMCE 1215 Homework #5-Mohr\'s Circle Spring 2018 Due Date: March 20th, 2018 A 1-in.-square steel bar is subjected to an axial tensile load od 10,000 lb. Use Mohr\'s circle to determine the shear stress and normal stress on a place that has a normal inclined at 60 counterclockwise from a plane perpendicular to the longitudinal axis of the member 1.

Solution

Draw a circle on the axes and find shear stress and normal stress by using distance formula or circle properties.
