As you can see the answers have already been provided for the question below, but I dont know the steps on how to get there, please write down the steps in detail thanks in advance.

The amplifier circuit, shown below uses an operational amplifier with the following small-signal parameters the voltage gain of 100,000V/V, the input resistance of 10KS2, the output resistance of 10K2. Ri -Rs 50S2, ANSWERS: : a) current amp b) -431.11 A/A | c) 47.02 , 10.91 k : d)-017A/A Rs a) b) c) d) e) f) State the type of feedback topology used in the amplifier circuit. Evaluate the open-loop gain of the amplifier Find the input and the output resistance of the open-loop amplifier. Calculate the feedback factor. Calculate the closed-loop gain of the amplifier. Find the input and the output resistance ofthe closed-loop amplifier. (1 mark) (2 marks) j (2 marks) e) -5.92 A/A (2 marks) (1 mark) (2 marks) f) 0.65 794.61 k

Solution

a) the type of feedback is decided by the connections of feedback element at input and output nodes, here the feedback is due to the resistor arrangement of R1,R2,R3 and this arrangement is directly connected to the input node at Negative opamp terminal and the arrangement is connected through the load resistor to the output node, thus it is direct connection at input and indirect at output which resembles a shunt mixing as the feedback element is in shunt with the source provided at input, and the output resembles a current sampling as the feedback is in series with the load resistance, thus the feedback is an shunt series feedback.this is called current sampling, the basic amplifier is current amplifier.

b)
