5. What multi-view(s) are considered to be related views? What makes them a related view? 6. What is a pictorial? Give an example 7. At a scale of 4:1, is the object larger than the drawing or visa versa. How much larger? Why learn how to sketch by hand when we have computers and software like AutoCAD and SolidWorks? 8. 3 5 6 8

Solution

Quesion number 5.)

In orthographic projection , we can have many Multi-views. These can be

Front view, Side view, Top view, Bottom View. Apart from these Auxiliary Views are also there.

Out of these any three adjacent views makes up the Related view.

For example,

Front, Side and top view are Related views.

Reason:

Any two adjacent side projections can help to project the third adjacent side. Hence, they are related to each other.

So, they are called Related views.
