As the wiper is moved from left to right 1 to 3 the resistan

As the wiper is moved from left to right (1 to 3). the resistance between terminals 1 and 2 Stays constant Increases Decreases Increases, then decreases What is the name of the physical component represented m Fig question 1 What instruments used in the lab to measure the voltage in a circuit Power supply DMM Function Generator Oscilloscope. A resistor with gold bar at the end have a tolerance rate of: 2% 5% 10% 20% When resistor tolerance of silver is taken into effect, the smallest acceptable value for R-1200 ohm is: 1000 ohm 1140 ohm 90S0 ohm 1080 ohm To measure the current in a circuit, the red probe should be connected to the: Current port of the DMM Ohm port of the DMM The black port of the DMM DMM are not used to measure current in a circuit.

Solution

1)B

2)RHEOSTAT

3)D

4) B

5) D

6) A
