1. Find the resistors values and capacitors values by calculation for this circuit.

2. Find the lower and higher frequency response.

47K 1k 470R 100mF mic 100nF BC547 BC547 8 76 100nF 4 7555 timer 9V 2 330R 4.7K Rookie Electronics

it is the clap switch diagram.

here BC547 Transistor is the NPN transistor

PIN CONFIGURATION OF 555 TIMER IS

pin-1 is the -Ve pin

pin-2 is the 2/3 Vcc (high)

pin-3 is the out put pin

pin-4 is the reset pin

pin-5 is the discharge pin

pin-6 is the 1/3 Vcc(low)

pin-7 is the control pin

pin-8 is the +Ve SUPPLY.

time (t)= RC

frequency(f)=1/t
