Phasor Domain Given The source functions in the above figure

Phasor Domain

Given: The source functions in the above figure are expressed such that frequencies are in radians per second while phase angles are in degrees.

Required: Calculate the magnitude and phase angle of the resulting rms phasor node voltages, V₁, and V₂.

N.B. The angles must be expressed in the range: -180 ° ? ? ? +180 °.

Solution:

V₁ = ___ ? ____^°

V₂ = ____ ? _____^°

50 20 8.0cos(1000t) A 40 rnH 40.0 F ) 250cos(1000t+60°) V

https://www.dropbox.com/s/cbbdicbwr3fz1e8/IMG_20160508_072114.jpg?dl=0
