The figure below shows C file 3pdf O B2400 O C3000 O D4800 7

The figure below shows...

C @file:/ 3.pdf O B.2,400 O C.3,000 O D.4,800 76. The figure below shows the flow net for the cross section of a dam that is 600 ft long (measured perpendicular to the cross section). Assuming a uniform cross section, the total seepage (ft/day) under the dam would be most nearly: 30 ft 50 ft 100 ft 60 ft k,-k, = 4 × 10 4 in./scc 63 37,800 51,840 O D. 453,600 O C. lype here to search

Solution

DIscharge = K*H*q_f/q_d

=4*10^-4*3600*24/12*50*(4/8)*600

=45360 ft³/day
