What do you observe in the plot below? (?_s = start of energy release)

Solution

>> This plot indicates that there are 4 cylinders in engine , all having different burning rate of fuel

>> and, Each engine has burning rate, i.e cobustion will occur during 60 degree of crank rotation.
