Recall the data acquisition system used in experiment 1 Iden

Recall the data acquisition system used in experiment 1. Identify and describe the system components that perform the following functions. Describe in terms of the stages of the measurement system.

Solution

SENSOR: Sensor is a sensing device which senses the data or any desired value which must be used to perform some function, eg Relay is one type of sensor

Transducer: Transducer is a device which converts any physical quantitities like Length,pressure,Temparature,humidity etc into corresponding electrical signals is called a Transducer

Signal Conditioning:

Signal conditionmers are devices which are used to convert any difficult or Unreadable signals into a simpler form called as signal conditioners,

For example Any unknown signals are converted into Digital signals during the measurement process in DVMs(Digital Voltmeters)

Output:

Output is the final stage in any circuit or any machines or any work,It may also called as the Response of the Desired system
