Calculate the net impedance Z_r in the given network. Please express your answer is both rectangular and polar form.

Solution

From the diagram, we can see that 4 ohm & j6 ohm resistance are in series and 2ohm & j2 ohm are in series and they are in parallel, and outside 2 ohm resistance is in parallel

hence Z inside the loop= (4 + j6) *(2 + j2) /(6 + j8) = (-4 + j20) / (6 + j8)

Zeq = 2*(-4 + j20) / (6 + j8) / { 2 + (-4 + j20) / (6 + j8)} ohm ...........Ans.
