Consider the internal structure of the pseudo-CPU discussed in class augmented with a single-port register file (i.e., only one register value can be read at a time) containing 32 8-bit registers (R31-R0) and a carry bit (C-bit), which is set/reset after each arithmetic operation. Suppose the pseudo-CPU can be used to implement the AVR instruction ADIW ZH:ZL,32 (Add immediate to word). ADIW is a 16-bit instruction, where the upper byte represents the opcode and the lower byte represents an immediate value, i.e., “32” (do not worry about the fact that the actual format is slightly different). Give the sequence of microoperations required to Fetch and Execute the ADIW instruction. Your solutions should result in exactly 5 cycles for the fetch cycle and 6 cycles for the execute cycle. Assume the memory is organized into addressable bytes (i.e., each memory word is a byte), MDR, IR, and AC registers are 8-bit wide, and PC and MAR registers are 16-bit wide. Also, assume Internal Data Bus is 16-bit wide and thus can handle 8-bit or 16-bit (as well as portion of 8-bit or 16-bit) transfers in one microoperation and only PC and AC have the capability to increment itself.

Solution

An arithmetic logic unit (ALU) is a combinational digital electronic circuit that performs arithmetic and bitwise operations on integerbinary numbers. This is in contrast to a floating-point unit (FPU), which operates on floating point numbers. An ALU is a fundamental building block of many types of computing circuits, including the central processing unit (CPU) of computers, FPUs, and graphics processing units (GPUs). A single CPU, FPU or GPU may contain multiple ALUs.

The inputs to an ALU are the data to be operated on, called operands, and a code indicating the operation to be performed and, optionally, status information from a previous operation; the ALU\'s output is the result of the performed operation.
