Two submodules partA and partB have been designed as two Verilog files partA.v and partB.v, readily available for use. module partA (x, y, d); input x, y; output reg [2:0] d; .... endmodule module partB(w, s); input [2:0] w; output s; ... endmodule The diagram of mycircuit is shown in Fig.2. Write a Verilog file for the top module part of module mycircuit by instantiating modules partA and partB. Use the signal names in the diagram for your Verilog codes.

Solution

module(f,x)

input [1:0] x;

output f;

wire [2:0] t;

partA A(x[1],x[0],t[2],t[1],t[0]);

partB B(t[2],t[1],t[0],f);

end module
