so i\'m practicing the pspice software. i have no issues with DC circuits, and currently working on AC circuits. but when i run the simulation, it returns 0V and 0A all over like so. and for the AC voltage source i have the settings like so

so i am wondering if there are any issues that can be fixed

and if possible, type up a response rather than hand write it.

Solution

what are the connections you have given are correct..

the output is also correct in the dc point of view.

But in AC point of view select resistor to see the output

Point the voltmeter across it now simulate the circuit.

The periodic wave is generated. It is the voltage across the resistor.
