Find the Vo.

Solution

consider the left side loop current as i1 and right side loop current as i2

both the currents are rotating in clockwise direction.

from the circuit

i2-i1=2*10^-3

apply kvl to loops i1 and i2.

-12+2000i1+6000i2=0

from the above equations

i1=0 amps

i2=2*10^-3 amps

vo=i2*2000=2*2*10^-3*10^+3=4 volts.
