Calculate the value of K on the 90 elbow and on tee if the p

Calculate the value of \"K\" on the 90° elbow, and on tee, if the pipes are made of commercial steel

(equation showing K)
(subject: Mechanical Fluids)

Also send me screenshot of the tables
showing where you got the value of t
the 90 degree elbow and on tee.

EFFICIENCY 50% Q8.3 GPM THERE ISA AND 1 IEE DIAMETER OF PIPE IS OF 1/2\" 20 cm DEPOSIT ELBOW 90 ELBOW 90\" 50 cm 30 cm

Solution

For 90deg elbows average value of k = 0.3

For Tee joints dividing the line flow, average value of k = 0.2
