The hexadecimal equivalent of decimal 1234 is A 2D4 B 4D2 C

The hexadecimal equivalent of decimal 1234 is A. 2D4. B. 4D2. C. 0001 0010 0011 0100. D. 0100 0011 0010 0001. The binary number system best suits digital electronic applications because A. linear outputs are provided by digital circuits. B. linear inputs are used by digital circuits. C. digital logic involves only two states or conditions. D. there is no borrowing in the binary system. What is meant by a binary input pattern? A. A group of bits that show enabling logic for a gate\'s input B. A pattern of bits that show inhibiting logic for a gate\'s input C. A digital step pulse that activates a gate D. A cluster of not-circles at a gate\'s inputs Which one of the following Boolean equations states that \"Q proves true only when every input value is true\"? A. Q = A + B + C B. Q = A middot B middot C C. Q = A B C D. Q = A times B times C The position value four places to the left in a binary number is A. decimal 1000. B. decimal 1111. C. decimal 4. D. decimal 8. Which of the following Boolean equations best describes a NOR function? A. Q = A middot B B. Q = A - B C. Q = A + B D. Q = A B Which one of the following Boolean equations states that Q is true when one - and only one-input is true. A. A = A + B + C B. Q = A middot B middot C C. A B C D. Q = A times B times C In a circuit where true is logic 0 and false is logic 1, the logic is said to be logic. A. positive B. negative C. three-state D. four-state Normally, in NEMA (National Electrical Manufacturers Association) logic schematics you would assume that input logic 1 A. Closes NO contacts and open NC contacts. B. Opens NO contacts and closes NC contacts. C. Closes both NO and NC contacts. D. Opens both NO and NC contacts.

Solution

6.Ans) B--4D2

Reason : 4D2 in hex converts decimal as follows-----4*16²+13*16+2*16⁰=1024+208+2=1234 decimal

-------------------------------------------------

7Ans) C-

digital logic involves only 2 states similary binary system involves two symbols 0 or 1,it best suits digital applications

-----------------------------------

Only 1 question per post will be answered pelase but I answered 2 here
