please solve the table the and show calculations. Battery Voltage = 60V

Please solve the table the and show calculations. Battery Voltage = 60V

Solution

R1=8

R2=8

R3=16

R4=10

R5=10

R12=8*8/16=4 ohm (R1 and R2 are in paralle)

R123 = 4+16 = 20 Ohm (R12 and 3 are in series)

R45= 20 ohm (R4 and 5 are in series.)

R12345= 10 ohm (R123 and R45 are in parallel).

so current through battery = 60/10=6 A

Current through R123 would be same as current through r45 and resistance is same

Current through R123= 3 A = current through R45.

Current through R1 and R2 would same . so current through R1=1.5 = current through R2.

Current through R3=3 A

1.5 A

battery	60V	6a
10 ohm	30V	3 A	10
10 ohm	30 V	3A	10
8 ohm	12 V	1.5 A	8
8 ohm	12 V	1.5A	8
16 ohm	48 V	3 A	16
